Capture every point of view in 4K with the black BRC-X400 4K PTZ Camera with HDMI, IP & 3G-SDI Output from Sony. Featuring an 8.3MP CMOS sensor and a 4.4 to 88mm lens, the camera captures video at resolutions up to 3840 x 2160 at 60 fps in a field of view of up to 70°. Clear Image Zoom Technology can extend the 20x optical to up to 80x, allowing for frame-filling close-ups in Full HD.
$5,200.00
Capture every point of view in 4K with the black BRC-X400 4K PTZ Camera with HDMI, IP & 3G-SDI Output from Sony. Featuring an 8.3MP CMOS sensor and a 4.4 to 88mm lens, the camera captures video at resolutions up to 3840 x 2160 at 60 fps in a field of view of up to 70°. Clear Image Zoom Technology can extend the 20x optical to up to 80x, allowing for frame-filling close-ups in Full HD.
The integrated pan/tilt system allows for 340° panning and 110° tilting at up to 300° and 126° per second respectively. Focusing can be performed manually or set to automatic. The camera outputs video via its HDMI, IP, and 3G-SDI interfaces. PoE+ technology simplifies setup by enabling you to power the camera directly via its network connection. An IR remote commander, mounting hardware, and an HDMI clamp are included in the package.
Key Features
1/2.5″ Exmor R sensor for UHD 4K images with very low noise, even in dimly-lit environments down to 1.6 lux
20x optical zoom
Up to 30x total zoom in 4K with Clear Image Zoom
Up to 80x total zoom in Full HD with Clear Image Zoom in Tele Convert Mode
Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings
Horizontal viewing angle of approximately 70° for covering the whole scene in large venues such as sport arenas and lecture theaters
NDI|HX compatibility via optional license
PTZ and other camera functions can be controlled remotely via S700PTP, CGI, and VISCA protocols
RTSP (Real Time Streaming Protocol) support for remote viewing over the internet from a web browser
PoE+ simplifies installation—a single IP cable can carry camera power, video image output, and control signals
Genlock allows seamless multi-camera switching in live events
Built-in tally lamp for use in live productions, reality shows, and more
Camera Features
Day/night, visibility enhancer, image stabilization, image flip, picture profile preset
Color gain (15-step), color hue (15-step)
Color matrix modes include Standard, High Saturation, FL Light, Movie, Still, Cinema, Pro, ITU709, and B&W
Gamma modes include Standard, Straight, 512 Pattern, Movie, Still, Cine1, Cine2, Cine3, Cine4, and ITU709
Gamma level (15-step), black level (97-step), black gamma (15-step)
Knee point (15-step), knee slope (15-step), flicker cancel (on/off)
UPC: 027242918061
Sony BRC-X400 Specs
Image Sensor
Image Sensor 1-Chip 1/2.5″ CMOS Sensor
Horizontal Resolution (TV Lines) 1700 TV Lines
Sensor Resolution 3840 x 2160 (8.3 MP)
Gain 0 to 48 dB
Minimum Illumination 1.6 Lux at 1/30 Shutter Speed
Camera
Shutter Speed 1/1 to 1/10,000 sec
Max Digital Zoom 80x ( in 1080p)
Flip / Mirror Support Image Flip
Lens
Optical Zoom Ratio 20x
Focal Length 4.4 to 88mm
Field of View Horizontal: 70°
Maximum Aperture f/2 to 3.8
Minimum Focusing Distance Wide: 3.1″ / 8.0 cm
Telephoto: 31.5″ / 80.0 cm
Focus Control Autofocus
Manual Focus
Video Output
Output Formats HDMI, RJ45: 3840 x 2160p at 23.98, 25, 29.97 fps
1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps
1920 x 1080i at 50 fps
1280 x 720p at 50, 59.94 fps
SDI: 1920 x 1080p at 23.98, 25, 29.97, 50, 59.94 fps
1920 x 1080i at 50, 59.94 fps
1280 x 720p at 50, 59.94 fps
Embedded Audio SDI: 2-Channel
HDMI: 2-Channel
Recording
Recording Modes Not Specified by Manufacturer
Control
Presets 256 via IP
100 via VISCA
Move Speed Pan: 0.5 to 300°/sec
Tilt: 0.5 to 126°/sec
Movement Range Pan: 340° (-170 to 170°)
Tilt: 110° (-20 to 90°)
Tally Light Yes
Supported Control Protocols IP
RS-422
VISCA
Interfaces
Video Output Connectors 1 x BNC (3G-SDI) Female
1 x HDMI Type A Female
1 x RJ45 Female
Audio I/O 2 x 1/8″ / 3.5 mm Stereo Mic/Line Level Input
Control Interface 1 x RJ45 (RS-422, VISCA) Input
1 x RJ45 (RS-422, VISCA) Output
Other I/O 1 x BNC (Sync) Input
Power
PoE Support PoE+ 802.3at
Power Connectors 1 x JEITA (10.8 to 13.2 VDC)
Power Consumption 25.5 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
General
Tripod Mounting Thread 1 x 1/4″-20 Female
Dimensions 7.88 x 6.99 x 6.24″ / 200.2 x 177.5 x 158.4 mm
Weight 3.97 lb / 1.8 kg
Packaging Info
Package Weight 8.135 lb
Box Dimensions (LxWxH) 12.8 x 12.7 x 12.2″
Manuals BRC-X400
Brochure: Network PTZ Cameras
Spec Sheet: PTZ Network Cameras
BRC & SRG Family Brochure V2.0
