Sony ELF-SR2 27in 4K Spatial Reality Display

Share...

Made with Sony’s Eye-Sensing Light Field Display (ELFD) technology, the Sony 27″ 4K Spatial Reality Display delivers an immersive 3D optical experience without 3D glasses or a VR headset. The 27″ display features a 3840 x 2160 resolution and is combined with Sony’s own proprietary high-speed vision sensor. The sensor follows your eyes in vertical, horizontal, and depth axes simultaneously. Monitoring your eye movement down to the millisecond, the sensor can render the image instantaneously. The result is a realistic, virtual 3D environment that can be seen from any angle without the need for additional hardware. For audio, there is a 1W monoaural speaker

$4,750.00

Looking for a better price?
Start a chat with one of our reps or give us a call.
GTIN: 027242926622 ELF-SR2 ELF-SR2 Category

Description

Made with Sony’s Eye-Sensing Light Field Display (ELFD) technology, the Sony 27″ 4K Spatial Reality Display delivers an immersive 3D optical experience without 3D glasses or a VR headset. The 27″ display features a 3840 x 2160 resolution and is combined with Sony’s own proprietary high-speed vision sensor. The sensor follows your eyes in vertical, horizontal, and depth axes simultaneously. Monitoring your eye movement down to the millisecond, the sensor can render the image instantaneously. The result is a realistic, virtual 3D environment that can be seen from any angle without the need for additional hardware. For audio, there is a 1W monoaural speaker

Compatible with Unity and Unreal Engine 4, the Spatial Reality Display can easily export new or existing 3D content, using Sony’s Software Development Kit (SDK). The Spatial Reality Display enables creators across various industries, from automotive and industrial design to computer graphics and visual effects designers, to bring ideas to life.

  • 27″ 4K Display
    The Spatial Reality Display features a 27″ screen with a 3840 x 2160 resolution.
  • High-Speed Vision Sensor
    The proprietary high-speed sensor follows your eye movement down to the millisecond, sensing pupil position through space on all three axes; vertical, horizontal, and depth.
  • Real-Time Rendering Algorithm
    Using an original algorithm, the Spatial Reality Display processes real-time content for each eye without lag. This allows the 3D world to appear as smooth as in real life, even if you move your position.
  • Micro-Optical Lens
    The micro-optical lens is positioned precisely over the 27″ display. This lens divides the image into the left and right eyes, allowing for stereoscopic viewing with just your eyes.

Sony ELF-SR2 Specs

Display
Size 27″
Screen Area 23.4 x 13.1″ / 593.2 x 332.8 mm
Panel Type LCD
Touchscreen No
Resolution 3840 x 2160
Aspect Ratio 16:9
Pixels Per Inch (ppi) 163 ppi
Finish Anti-Glare / Matte
Maximum Brightness 400 nits / cd/m2
Contrast Ratio 1000:1
Variable Refresh Technology None
Bit Depth / Color Support 8-Bit+FRC (1.07 Billion Colors)
HDR Compatibility None
Color Gamut 100% Adobe RGB
Response Time 14 ms
Inputs / Outputs
Inputs/Outputs 1 x HDMI 2.0
1 x DisplayPort 1.2
1 x USB-C (USB 2.0)
1 x USB-A
1 x 1/8″ / 3.5 mm Output
Built-In Speakers Yes, 1 x 1 W
Media Card Reader None
Multi-Input Support (PIP/PBP) None
Power
Power Consumption 64 W (Maximum)
0.5 W (Standby)
Power Adapter Type External
USB Power Delivery None
DC Input Power 19.5 VDC at 3.3 A
Environmental
Operating Humidity 20 to 80%
Physical
Height Adjustment None
Rotation Adjustment None
Swivel Adjustment None
Tilt Adjustment None
Max Arm Extension Length None
Mounting-Hole Pattern 100 x 100 mm
Lock Slot No
Dimensions (W x H x D) 24.8 x 11.9 x 12.2″ / 631.0 x 303.0 x 309.0 mm (with Stand)
24.5 x 16.5 x 2.0″ / 622.0 x 419.0 x 51.0 mm (without Stand)
Weight 18.1 lb / 8.2 kg (with Stand)
14.3 lb / 6.5 kg (without Stand)

Additional information

Weight 18.1 lbs
Dimensions 24.8 × 11.9 × 12.2 in

Brand

Sony

Sony projectors feature the latest in projection technology. From ultra-short to portables to large venue projectors, Sony's expanded lineup simply works- more efficient, reliable, and easier to use.
