Description
Made with Sony’s Eye-Sensing Light Field Display (ELFD) technology, the Sony 27″ 4K Spatial Reality Display delivers an immersive 3D optical experience without 3D glasses or a VR headset. The 27″ display features a 3840 x 2160 resolution and is combined with Sony’s own proprietary high-speed vision sensor. The sensor follows your eyes in vertical, horizontal, and depth axes simultaneously. Monitoring your eye movement down to the millisecond, the sensor can render the image instantaneously. The result is a realistic, virtual 3D environment that can be seen from any angle without the need for additional hardware. For audio, there is a 1W monoaural speaker
Compatible with Unity and Unreal Engine 4, the Spatial Reality Display can easily export new or existing 3D content, using Sony’s Software Development Kit (SDK). The Spatial Reality Display enables creators across various industries, from automotive and industrial design to computer graphics and visual effects designers, to bring ideas to life.
- 27″ 4K Display
The Spatial Reality Display features a 27″ screen with a 3840 x 2160 resolution. - High-Speed Vision Sensor
The proprietary high-speed sensor follows your eye movement down to the millisecond, sensing pupil position through space on all three axes; vertical, horizontal, and depth. - Real-Time Rendering Algorithm
Using an original algorithm, the Spatial Reality Display processes real-time content for each eye without lag. This allows the 3D world to appear as smooth as in real life, even if you move your position. - Micro-Optical Lens
The micro-optical lens is positioned precisely over the 27″ display. This lens divides the image into the left and right eyes, allowing for stereoscopic viewing with just your eyes.
Sony ELF-SR2 Specs
Size | 27″ |
Screen Area | 23.4 x 13.1″ / 593.2 x 332.8 mm |
Panel Type | LCD |
Touchscreen | No |
Resolution | 3840 x 2160 |
Aspect Ratio | 16:9 |
Pixels Per Inch (ppi) | 163 ppi |
Finish | Anti-Glare / Matte |
Maximum Brightness | 400 nits / cd/m2 |
Contrast Ratio | 1000:1 |
Variable Refresh Technology | None |
Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) |
HDR Compatibility | None |
Color Gamut | 100% Adobe RGB |
Response Time | 14 ms |
Inputs/Outputs | 1 x HDMI 2.0 1 x DisplayPort 1.2 1 x USB-C (USB 2.0) 1 x USB-A 1 x 1/8″ / 3.5 mm Output |
Built-In Speakers | Yes, 1 x 1 W |
Media Card Reader | None |
Multi-Input Support (PIP/PBP) | None |
Power Consumption | 64 W (Maximum) 0.5 W (Standby) |
Power Adapter Type | External |
USB Power Delivery | None |
DC Input Power | 19.5 VDC at 3.3 A |
Operating Humidity | 20 to 80% |
Height Adjustment | None |
Rotation Adjustment | None |
Swivel Adjustment | None |
Tilt Adjustment | None |
Max Arm Extension Length | None |
Mounting-Hole Pattern | 100 x 100 mm |
Lock Slot | No |
Dimensions (W x H x D) | 24.8 x 11.9 x 12.2″ / 631.0 x 303.0 x 309.0 mm (with Stand) 24.5 x 16.5 x 2.0″ / 622.0 x 419.0 x 51.0 mm (without Stand) |
Weight | 18.1 lb / 8.2 kg (with Stand) 14.3 lb / 6.5 kg (without Stand) |
