Description
The ASB6125 from JBL is a professional-quality passive subwoofer that provides strong, reliable bass performance for a variety of applications. The wooden cabinet houses a pair of 15″ Differential Drive dual voice coil drivers with large neodymium magnets for a long performance life. The subwoofer can operate in parallel or discrete input modes for excellent versatility. The 14-gauge steel grille is lined with acoustically transparent foam to protect the driver. The subwoofer has a 1600W (6400W Peak) power rating and has a large vent area to provide high output with low distortion. The enclosure has 16 threaded M10 attachment points to provide versatile mounting options.
Wooden cabinet with DuraFlex finish
Pair of 15″ Differential Drive dual voice coil drivers with large neodymium magnets for a long performance life
Switchable parallel/discrete input modes provide versatility
14-gauge steel grille is lined with acoustically transparent foam to protect the driver
Power rating of 1600W (6400W peak)
Large vent area provides high output with low distortion
16 threaded M10 attachment points provide various mounting options
JBL ASB6125 Specs
Driver 2 x 15″ (380mm) Differential Drive Woofer with 3″ Dual Coil Dual Gap Neodymium Magnet
Crossover Not Specified by Manufacturer
Frequency Range 32 Hz – 1 kHz
Impedance 4 ohms (parallel)
2 x 8 ohms (discrete)
Maximum Power Handling 1600 W (6400 W peak), 2 h
1350 W (5400 W peak), 100 h
Maximum Sound Pressure Level (SPL) 132 dB
Controls and Indicators None
Connectors 1 x NL4 Neutrik Speakon Input
1 x Barrier Strip Terminal
Shielded No
Enclosure Material 11-Ply birch plywood with DuraFlex finish
14-Gauge steel grille with acoustically transparent foam
Dimensions (HxWxD) 38.0 x 16.5 x 23.5″ (965.0 x 419.0 x 597.0 mm)
Weight 81.0 lb (36.7 kg)
Packaging Info
Package Weight 97.02 lb
