Description
Experience bright, high-contrast images and ultrasmooth gaming with the LX700-4K 3500-Lumen UHD 4K Laser DLP Home Theater and Gaming Projector from ViewSonic. The LX700-4K utilizes laser and DLP technology to deliver consistent brightness and color over 20,000+ hours of life without having to change a lamp.
Connect HD and UHD devices via HDMI 2.0 inputs, including one with eARC, to witness 4K 60 Hz and 1080p 120 Hz resolution. As part of the Designed for Xbox series, the LX700-4K is optimized for playing Xbox games with 1440p 120 Hz resolution. With a throw ratio of 1.06-1.45:1, this projector can fill a 95 to 130-inch diagonal screen from just 10 feet away. Additionally, it provides flexible installation with vertical lens shift, H/V keystone, and four-corner correction.
Designed for Xbox
For immersive gaming, the LX700-4K supports an Xbox-exclusive resolution and refresh rate combination. The combination of QHD 1440p resolution and 120 Hz refresh rate strikes a perfect balance for a high-quality and smooth gaming experience, allowing the LX700-4K to project imagery with detail and clarity, even during fast-moving scenes.
Support for 1080p 240Hz Gaming
Boasting 4.2 ms ultra-fast input, a hyper-responsive 240 Hz refresh rate, and a microsecond-level response time from the DMD chip, the projector delivers seamless viewing in high-intensity scenes.¿ The default refresh rate is 60 Hz. To enable ultra-fast input, it needs to be activated in the Advanced Settings menu and content needs to be configured for 240 Hz. When enabled the highest resolution supported is 1080p.
Additional Features
Up to 30,000 hours of laser life
HDR10 and HLG support
High native contrast ratio with 0.65″ DMD chip
Vertical lens shift
1.36x optical zoom
Horizontal and vertical keystone correction
Four-corner adjustment
USB-A power out for streaming dongle
SuperColor technology for wide color gamut
HDMI eARC
3.5mm 12V trigger
UPC: 766907023961
ViewSonic LX700-4K Specs
Key Specs
Display System
1-Chip 0.65″ DMD DLP
Native Resolution
3840 x 2160
Maximum Brightness
3500 Lumens (ANSI)
Throw Ratio
1.06 to 1.45:1 (100″ Screen Size @ 7.71′ / 2.35 m)
Projection Size
30 to 300″ / .8 to 7.6 m
HDR Support
Yes, HDR10/Hybrid Log Gamma
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x 1/8″ / 3.5 mm Mini Audio Output
1x USB-A Power, Service Input/Output
1x 12 V Trigger Control Output
1x DE-9/DB-9 (RS-232) Control Input/Output
Show More
Light Source
Laser Phosphor
Image Display
Display System
1-Chip 0.65″ DMD DLP
Native Resolution
3840 x 2160
Supported Resolutions
Maximum: 3840 x 2160 @ 60 Hz
2560 x 1440 @ 120 Hz
1920 x 1080 @ 240 Hz
Maximum Brightness
3500 Lumens (ANSI)
Offset
137% ± 10% vertical
Aspect Ratio
Native: 16:9
Supported: 4:3
Dynamic Contrast Ratio
3,000,000:1
DLP Link 3D
Yes
Supported 3D Formats
Side by Side (up to 1080p)
Top Bottom (up to 1080p)
Frame Sequential (up to 1080p)
Color Depth
10-Bit (1.07 Billion Colors)
Scan
Horizontal: 15 to 135 kHz
Vertical: 23 to 240 Hz
Latency
4.2 ms
Lens
Includes Lens
Yes
Focus
Manual
Aperture
f/2.51 to 2.93
Focal Length
15.985 to 21.423mm
Lens Shift
Vertical: 0 – 15%
Optical Zoom
Manual: 1.36x
Throw Distance
2.3 – 31.59′ / 0.7 – 9.63 m
Throw Ratio
1.06 to 1.45:1 (100″ Screen Size @ 7.71′ / 2.35 m)
Projection Size
30 to 300″ / .8 to 7.6 m
Features
Keystone Correction
Manual to Vertical: ± 30°
Manual to Horizontal: ± 30°
HDR Support
Yes, HDR10/Hybrid Log Gamma
Digital Zoom
2.0x
Multi-Input Support (PIP/PBP)
Not Specified by Manufacturer
Ceiling Mountable
Yes
Rear Screen Projection
Yes
Built-In Speaker
Yes (Mono)
Speaker Power
15 W
Projection Tilt Option
Yes
Input/Output Connectors
Inputs/Outputs
2x HDMI 2.0b Audio, Video Input
1x 1/8″ / 3.5 mm Mini Audio Output
1x USB-A Power, Service Input/Output
1x 12 V Trigger Control Output
1x DE-9/DB-9 (RS-232) Control Input/Output
HDCP Support
Yes, Version 2.2
Media/Memory Card Slot
No
Hardware
Mobile App Compatible
No
Wireless LAN / Wi-Fi
No
Bluetooth
No
General
Light Source
Laser Phosphor
Expected Lamp Life
Low Brightness: 30,000 Hours
Full Brightness: 20,000 Hours
Fan Noise
Full Brightness: 31 dB
Low Brightness: 26 dB
Security
Keypad Lock
Password Protection
Security Bar
Supported Languages
Arabic
Czech
Dutch
English
Finnish
French
German
Greek
Indonesian
Italian
Japanese
Korean
Norwegian
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Thai
Traditional Chinese
Turkish
Vietnamese
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
Medium Brightness: 180 W
Standby Mode (Lamp Off): < 0.5 W
Certifications
FCC, ICES-003, CE, WEEE, RoHS2
Operating Temperature
32 to 104°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
10 to 80%
Storage Humidity
5 to 90%
Dimensions (W x H x D)
11.3 x 5.1 x 8.5" / 286.0 x 129.0 x 216.0 mm
Weight
7.28 lb / 3.3 kg
